Programming mode 4
Insert and delete a program segment
Start the programming procedure up to " XX.id XX".
å
To insert a program segment
Press " START ".
XX. inS = Insert
Then press " E ".
The program segment " XX " moves up one place to the following number. " XX.id XX " will appear again
on the display. This program segment can now again be programmed.
Example:
Program " 01 " with 4 program segments (01, 02, 03, 04).
Suppose one segment should be inserted between 02 and 03.
Select " 01.id 03" and press " START ". " 03 ins " appears on the display. Press " E ". Now " 01.id 03 " will
appear once more. The program segment 03 must be put in again.
The previous segment 03 moves up to 04 and the previous 04 will become 05.
If there is not enough space in the Ram memory, the error message " Ram full " will appear.
To delete a program segment
Press " STOP ".
XX. del (flashing) = delete
Press " E ".
The program segment " XX " will now be deleted. The following program segments will move back one
place.
Example:
Program 01 with 4 segments (01, 02, 03, 04).
Segment 02 must be deleted.
Select " 01.id 02 " and press " STOP ". " 02 del " will appear on the display. Press " E ".
Now " 01.id 02 " will appear once more. This was previously program segment " 03 ". Program segment
å
04 was moved back to 03.
Program tables
The table on the next page shows how the programmed data are registered.
