47
Test mode 7
Test 3: coin meters
In this test the operation of the coin meter is tested.
" t3.0 " will appear on the display.
Every time a coin is inserted, the sum is made of all inserted coins and the new value will appear.
By pressing the 0 button this value returns to 0.
Press the " STOP " button to leave this test.
Test 4: Control of water level sensor
In this test you can see the water level changing per 1/10 unit.
" t4.LEV 00.0 " will appear.
By pressing " START " now the drain valve will be closed and water is taken through I2.
The respective level is shown on the display.
If you press " STOP " the water inlet is temporarily interrupted until you press "START " once more.
To stop this test, press the " STOP " button.
Test 5: Control of temperature sensor
" t5. XX.X " will appear on the display. " XX.X " stands for the respective temperature in the tub.
To stop this test, press the " STOP " button.
Test 6: Control of the 24 exits
With this test you can activate each exit contact one after the other.
Exit 17: water inlet I7
Exit 18: water inlet I6
Exit 19: water inlet I5
Exit 20: water inlet I4
Exit 21: water inlet I3
Exit 22: water inlet I2
Exit 23: water inlet I1
Exit 24: soap inlet 6
Exit 9: high spin
Exit 10: low spin
Exit 11: distribution speed
Exit 12: wash action right
Exit 13: wash action left
Exit 14: heating
Exit 15: water inlet cool-down
Exit 16: water inlet I8
Exit 1: soap inlet 1
Exit 2: soap inlet 2
Exit 3: soap inlet 3
Exit 4: soap inlet 4
Exit 5: soap inlet 5
Exit 6: drain valve 1
Exit 7: drain valve 2
Exit 8: door lock
Example:
" t6.out 22.o " = Exit 22 (water inlet I2) is open.
You can close this exit contact by pressing 1 and water is taken via this valve.
On the di.splay appears:
" t6.out 22.c " = Exit 22 (water inlet I2) is closed.
To open this entry contact again, press 0.
To control the next exit, press " E ".
To control the previous exit, press " NO ".
To stop this test, press the " STOP " button.
Test 7: Keyboard
" t8. -- " appears on the display.
For each key you press on the keyboard, the respective function is shown.
To stop this test, press the " STOP " button twice.
Ram reset
With this function the entire data in the Ram memory is erased.
Press 0 when " tESt " appears.
On the display " Code " is shown.
Put in " 7 5 3 " (press quickly one afer the other).
By doing a Ram reset all the manually programmed program segments are erased.
