Thank you for purchasing a Total Control controller. Listed below are some important
features you should be aware of before you begin programming. Details on how to
implement these features are described on the following pages.
• Four fully-independent programs which can be set to run concurrently or to be stacked
for delayed operation
• Watering programmable for days of the week, odd dates, even dates or intervals from 1
to 30 days. Selective removal of days from the Odd/Even schedule. For example, water
on Even numbered dates except Sundays.
• 365-day calendar, with automatic compensation for leap year
• Sixteen total start times to use in any program
• Station watering time from 0 minutes to 10 hours in 1-minute increments
• Program erase independent for each program
• Non-volatile memory that retains programmed information for up to 30 years in the
event of a power failure
• Accurate time and date retention during power failures for up to 90 days continuous via
a 9-volt alkaline battery (included)
• % Water Budget (Seasonal and/or Monthly) from 0 to 200% in 10% increments
• Rain delay programmable to 7 days
• Self-diagnostic electronic circuit breaker that identifi es and over-rides faulty stations
• Master valve/pump start operation selectable per program
• Complete manual operations available by station and program
• Sensor switch-ready for operation with any normally-closed rain switch device
• Slide switch control provided for rain sensor override
• Compatible with Irritrol Climate Logic
TM
weather sensor system.
• Unique modular design for ease of installation and service
• Wire connection terminal blocks can accommodate two 12 AWG (4 mm2) stranded
or solid copper wires per station. Color-coded quick connect terminals for ease of
installation and service.
To take full advantage of all Total Control features, please review the User’s Guide
completely before installing or programming your new controller.
FEATURES
