Irritrol Total Control User Manual

7
All Total Control controllers have the potential for connection of third party radio receivers
or control devices. This feature is enabled in 36- and 48-station controller terminal boards
through a 6-pin remote port.
NOTE: This feature is for the connection of third-party devices. The Irritrol CMR-1 does
not require this setting.
1. Turn the dial to % Water Budget position.
2. Press the NEXT button until R-ON, R-OFF or R-CEN is displayed.
3. Press either the + /ON or the – /OFF button to toggle between the following options:
R-OFF: Remote radio communications are Disabled.
R-ON: Remote radio communications are Enabled.
R-CEN: Enables a third party device to take complete control of the controller station
outputs.
IMPORTANT! This seting disables all Automatic and Manual operation from the
Total Control Control Module.
4. Turn the dial to the RUN position.
This section covers the following topics:
REMOTE RADIO COMMUNICATION FEATURE
