DOC. MIE91093 Rev. 1.34 Page 91 of 145

PH 3-1

1 PH

Note: in phase to phase faults, currents are equal in module

and opposite in phase.

CONNECTION OF THREE T1000 PLUS TO THE DISTANCE RELAY
