GLS Sampler
2-16
• Generate internal pump tables to
“measure” the liquid volume
• Calculate the suction head.
By calculating the suction head, the delivered
volumes are not affected by varying liquid
levels. The GLS automatically calculates the
suction head using input from the Liquid
Detector.
Note
Incorrect suction line values or disabling the liquid
detector may adversely affect the volume accuracy.
Note
Calibrating the sampler can enhance sample volume
accuracy.
To calibrate sample volumes, press the
Calibrate button and follow the steps:
1. Enter the suction line size.
2. Enter the suction line length.
SUCTION LINE SIZE:
1/4 inch 3/8 inch
SUCTION LINE LENGTH:
25 ft (3-99)
