Product Parameters and Characteristics
Thank you for purchasing the ISDT Q6 Plus Charger.
This Manual will guide you how to use Q6 Plus and its important functions.
You can know more about relevant information of IDST products by following this
link: www.isdt.co
1. 2.4”IPS Display
2. Power Input
3. Update Port
4. Opto- sensor
5. Speed Shuttle key
6. Balanced Port
7. Battery Port
Guide For the
Connection
of Balanced Port
2
3
1
4
5
6
7
Speed Shuttle key
Long press: enter system setting / terminate current task
Short press: enter task setting / conrm current setting
Horizontal scroll: select menu
