3
● Find the front wheel.
● Remove the QR skewer from the fork.
● Loosen the thumb nut of the QR skewer and remove it. Make sure the small ends of the two
cone springs face inwards.
● Lower the fork onto the front wheel. Make sure the brake rotor is between the brake pads of
the brake caliper and the axle passes through the fork dropouts.
● Keep the QR skewer in line with the axle and tighten the thumb nut until the QR skewer is
parallel to the floor.
● Close the QR lever completely with your palm, keeping the lever not touching the brake rotor.
● The disc brake rotor is located on the left side of the bike.
● Make sure the front wheel hub is completely engaged in the fork dropouts.
● Tighen the thumb nut and close the QR lever. The recommended torque is 30~40 N.m.
3.2 Install the front wheel
Warning
1 2
3
4
To Next Page
