iSinwheel U2 - Install Front Fender and Light; Install Stem and Handlebar

44
● Find the fender, and remove the
bolts and spacers on the fork arch and the
bolts at the bottom of the fork legs.
● Pass the fender through the fork's lower
legs and then tighten the bolts holding the
lower part of the fender.
● Tighten the screw that holds the fender
and front light with an appropriate hex key.
● Hold the fender and front light mount
and align the screw hole on the upper of
the fender and the screw hole of the front
light mount to the arch screw hole.
● Place the stem into the steerer tube,
adjust the stem to the desired height, and
then tighten the bolt holding the stem to
the steerer tube. Make sure the marker on
the stem lower part is fully inserted with
the marker line under the locknut. Align
the valve stem to the front tyre and tighten
the stem bolt.
3.3 Install the front fender and light
3.4 Install the stem and handlebar
1
2
3 4
