6
● Adjust the seat so that the seat is parallel to
the top tube. Close the QR lever to lock the
seat with your palm or fingers.
● Remove the screws and nuts pre-installed
on the seat stays and the 2 screws
on the bottom ends of the seat stays.
● Identify the correct sides by locating the 'R' and 'L' marks on the pedals.
● Tighten the pedals with hands at first. Spin the right pedal clockwise and the left pedal
counterclockwise.
●Then tighten the pedals with the provided open-end spanner.
3.6 Install the pedals
3.7 Install the rear fender, rear rack and light
L
R
To Next Page
