Default state is Energy consumption.
If multiple bits are selected, then values are cycling with period defined in MODBUS register 40174.
40174
LCD cycling period
Cycling time in Seconds
Table 2: LCD cycling period
Custom string is defined in register 47063:
47063
LCD Custom string
8 bytes to display on 7-segment LCD (non printable
values are replaced with empty space)
Table 3: LCD Custom string
Custom string has configurable label in register 47064:
47064
LCD Custom string label
4 bytes to display on 7-segment LCD (non printable
values are replaced with empty space)
Table 4: LCD custom string label
Value
Clock status
LCD status
0
Not sync (U)
u
1
Informative clock
i
2
Synchronized clock
S
3
Relative clock
r
Table 5: Clock sync status
Register 47000
Value
Charging Status
LCD status
0
Not charging (Idle)
I
1
Charging
C
2
Charging after power down
P
3
Charging after meter reset
d
Table 6: Charging status
