iSpring Water Systems Page 7
Installation
A. RO Faucet Installation
The RO faucet may be installed on any flat surface. Check the underside of
the location for any interference. You may use the existing predrilled hole
on the sink. Make sure the washer is big enough to cover the hole. If you
drill a new hole on the countertop or sink, make sure that drilling the hole
will not damage any pipe or wiring underneath the countertop or sink.
1. Determine the desired location for your RO faucet on your sink surface.
2. Place masking tape or duct tape on the location where the hole will be drilled.
3. Use a variable-speed drill set on slow speed and drill with a 1/8 inch (3 mm)
drill bit to make a center hole at the select location. Use lubricating oil to keep
the drill bit cool while drilling.
4. Enlarge the hole using a 1/4 inch (6.4 mm) drill bit following factory-approved
methods or approved plumbing practices.
5. Enlarge the hole to a 7/16 inch (11 mm) diameter. Keep the bit well oiled and
drill slowly.
6. On top of the sink, insert the small rubber washers, the base plate
(escutcheon plate), and the large rubber washer in that order over the
threaded mounting tube at the base of the faucet.
7. Under the sink, install the large metal (or plastic) washer and the star washer
(lock washer) over the threaded stem. Screw on the nut and tighten.
8. Slide the push-in fitting up the push-in adapter on the base, then lock it in
place by sliding the blue clip under the collet. Insert the Blue tubing about 1/2
inch into the push fitting, and again, secure it with the blue clip.
