iSpring Water Systems Page 5
Tubing Connection Guide
Cut the tubing squarely, and insert
tubing into the lock fitting (be sure the
lock fitting is flush for a secure insert).
Push tubing inward while pushing the
lock fitting outward and insert the lock
pin.
Pull on the tubing gently to ensure it is
tightly fitted.
CAUTION: Before cutting supplied tubings, predetermine the length by measuring the
distance between the components to be connected.
