DCM600 to 1800 - Instruction Manual
PARTS LIST FIG A , D 1, D2, E
# STOCK DESCRIPTION
1
324503 PUSH IN FITTING
2
324571
POLYURTHANE TUBING
1/4’’
3
324561 PUSH IN FITTING 90° 1/8’’
# STOCK DESCRIPTION
4
616770 SEALED CONNECTOR 3/8’’
5
616535 WATERPROOF CABLE 3/8’’
6
608572 GOYEN VALVE 1/8’’ 120V
Figure F
PARTS LIST FIGURE F
SEQUENTIAL CONTROLLER
Sequential controller DCT-1000 dust collector used in conjunction with pressure module DCP 100
Their operation is described in the documents attached pages 35 to 38.
DCP 100
Pressure module
# 908704
DCT 100
Static pressure
indicator
DCT 1000
Sequencer
# 908702
To Next Page
