DCM600 to 1800 - Instruction Manual
WARNING
After motor is connected
check if rotation is
corresponding
with arrow
.
ATTENTION
Après branchement
vérifier si la direction
de rotation correspond à
la flèche.
PRESSION DE TRAVAIL
MAXIMUM
WORKING PRESSURE
552 KPa
80 psi (lb/po
2
)
SPECIFICATIONS
DESCRIPTION DCM 600 DCM 900 DCM 1200 DCM 1800
Cartridge number
2
4
Filtration (sqft) 562 562 1124 1124
Recycler
13
16 26 30
Motor (hp)
1
2 3 5
Turbine (cfm)
600
900 1200 1800
Turbine (dB A)
82
84
Muffler (dB A)
76
Operating pressure
(psi)
80
Voltage (V)
120
460 / 575 460 / 575 460 / 575
Consumption (kW)
1.0
2.7 / 2.68 3.82 /3.88 6.05/6.07
Amperage (A)
8.4
3.4 / 3.7 4.8 / 3.9 7.6 / 6.1
Weight (lb)
900
915 1100 1150
Warranty
1 year
