SIEMENS KTP400 touch-screen screen
COUNTERS
Access "COUNTERS" from the main menu by pressing .
To erase the partial counters of the bay, press on the partial counter takings screen of the relevant bay. Total
counters cannot be erased. From the counter takings screen, time counters per program can be viewed pressing
.
Partial
counters
PARTIAL COUNTERS
TYPE
TYPE
Coins Accounting
Token Accounting
PARTIAL COUNTERS
Total
counters
TOTAL COUNTERS
TYPE TYPE
TOTAL COUNTERS
Taking, coins
Taking, tickets
Taking, pump hours
CONFIGURATION
Access CONFIGURATION from the main menu by pressing .
Program
conguration
Control
Money
Timers
Sequences (BY TIME)
Communication and connections
Fluids
Backup/Restore
