ITC T-4120UC User Manual

12
6. SCREEN OPERATION INSTRUCTIONS
Play control
Control play/pause, last/next song, volume increase and decrease through the button area on the
machine panel. In addition, the "MENU" knob can be used to control play/pause.
Play mode switch
Use the "MENU" knob to select the one indicated by the number 9 in the figure, short press the
"MENU" knob to cycle through the 4 playback modes: List loop, Single cycle, Order playback
and Single playback.
Play media switching
Use the "MENU" knob to select "TF" or "USB", and short press the "MENU" knob to switch to the
"TF" or "USB" mode. Of course, if the "TF" or "USB" is not inserted, the switch cannot be successful.
6. Play/Pause button;
7. Play time;
8. Song duration;
9. Play mode (List loop, Single cycle, Order playback, Single playback);
10. Song number and song file name;
11. USB mode indication, when highlighted, it means it is in USB mode.
3.2 FM radio
The FM interface is shown in the figure below, which can display basic information such as
channel number, channel frequency, playback status, and volume, specific:
FM radio
1
2
3
4
5
1.Return button;
2.Channel number;
3.Channel frequency;
4.Play/Stop button;
5.Volume.
In addition, long press the play/pause button to perform a re-searching operation. As shown in
the figure below, “Searching” will be displayed in front of the channel number, indicating that
the channel is searching. After the search is completed, the display screen will automatically
remove the “Searching” letter display.
FM in searching

ITC T-4120UC Specifications

General

Brand	ITC
Model	T-4120UC
Category	Amplifier
Language	English
