2. GENERAL DESCRIPTION
5
3. FEATURES
The new UC series of digital mixer amplifiers are more efficient and a cost-effective solution
specially developed to meet the needs of the global market. It is suitable for commercial audio
installations. Just to meet the needs of emerging markets to provide high-quality equipment at an
affordable price, the UC series mixer amplifiers are equipped with 4R and 100V two-way outputs
and a series of convenient functions, which are flexible and applicable worldwide. The series
combines many convenient and flexible functions, including Bluetooth and USB media player;
low impedance function (4ohm/8ohm) and high impedance output (100V); each output channel is
equipped with a separate bass and treble control.
1. 4 channels output, 120W/240W constant impedance or constant voltage high performance
digital mixer amplifier (4-16R/100V).
2. Built-in MP3 recording function.
3. 6-channel independent volume control.
4. The 6-channel audio source can be configured as a matrix to each channel output.
5. INPUT1-4 input with adjustable gain control.
6. The 4 outputs are with independent volume control.
7. Remote microphone input, max can be 4 remote microphones.
8. Built-in MP3 (U disk/SD card) player function.
9. Built-in FM radio function.
10. With high-end TFT display.
11. 4 outputs can remotely control the panel to adjust the circuit.
12. There are distortion, protection, signal, output status indicators.
13. INPUT1-4 channels can be configured with phantom power.
14. INPUT1-4 channels have priority and mixing selection function.
15. Priority input port for EMC alarm.
16. ALARM interface plays the specified alarm music.
17. Built-in Bluetooth function, can be connected to mobile phone/computer, with external high-
gain Bluetooth antenna.
18. 4 mute interfaces can be connected to the fire control interface.
19. Priority: EMC >MUTE REMOTE MIC INPUT1-4 LINE1-2.> > >
