This product is a six zones mixer amplifier, combining of high-performance switching power supply+H
-class amplifier chip Built in Bluetooth and Tuner, with 2U chassis design, high efficiency, light weight,
beautiful appearance.
2. GENERAL DESCRIPTION
1. 4 channel Mic inputs, 2 channel line inputs, separated treble and bass control.
2. 6 zone outputs with independent volume control.
3. Built-in chime, chime tone optional: 4 tones and 2 tones (built-in), alarm generator.
4. MP3 decoder module supports USB / SD / Bluetooth / FM Tuner playback. Configure MP3 remote
control, support power-off memory, MIC recording function.
5. When start the built-in generator, the background music will be off and 6-channel zone output will be
on automatically, switch output volume to be maximum.
6. Built-in 24V DC power input.
7. MIC1-4 built-in 48V phantom power, with independent control switch.
8. T-216 remote control microphone can remote control zones outputs, up to 6 units cascaded .
9. The audio input with separate control, tone control and master volume control.
10. A variety of LED display (signal, clip, protection LED indicator).
11. With fan forced cooling structure, to ensure long time working.
12. There are 5 level priority functions:
The first level of EMC priority: When the EMC alarm signal input,it will force to close all
audio sources, 6-way partition output will automatically open.
The second level of alarm generator,except EMC input,It is higher priority than any other
signal input, will force to close all other audio sources,6-way partition output will
automatically open.
The third level of built-in TEL/REM MIC,it is higher priority than MIC1-4,LINE1-2,bell tone.
The fourth level of built-in bell tone,it is higher priority than MIC1-4,LINE1-2.
The fifth level of built-in MIC1,it is higher priority than MIC2-4,LINE1-2.
13. The constant voltage output: 70V, 100V, constant impedance output: 4-16Ω.
5
3. FEATURES
