ITC TS-W100 User Manual

14
Specification
：
Mode
TS-W101/TS-W101A
Mic Type
Heart-oriented directional electret
Frequency Response
80Hz~16KHz
Microphone input impedance
1KΩ
Sensitivity
-46dBV/Pa
Maximum SPL
100dB(THD>3%)
SNR
>80dB(A)
Crosstalk
>70dB
Dynamic Range
>80dB
THD
<0.1%
Maximum power consumption
4 W
Headphone load
>16Ω
Headphone volume
Max 40mW
Headphone interface
3.5mm Mono jacks
Standards
IEC60914
Power supply
Battery powered
Color
Gray
Voting function
Five-button election, three-button vote, a custom vote
Sign-in function
Press the key to sign in
Display screen
4.3 inch color screen
Size (length x width x height)
196x134x63(mm)
Installation method
Desktop style
Radio frequency range
5 GHz
Battery capacity
12900mAh
Weight
approximately 0.7Kg
Standby mode work duration
24hours
Speech mode work duration
15hours
Mixed mode working hours
14hours
