Power Supply Function
Us Clamping
voltage
24V Select the 24V volt-
age system
Td Test pulse
width
Un Peak voltage
Us Clamping
voltage
Test–2B
Transient from DC motors acting as generators after ignition switch OFF:
Parameters 12V 24V
V
S
10V 20V
R
i
≤0.05Ω ≤0.05Ω
t
d
0.2–2s 0.2–2s
t
1
1ms±50% 1ms±50%
t
r
1ms±50% 1ms±50%
t
6
1ms±50% 1ms±50%
Copyright © Itech Electronic Co., Ltd.
103
