Quick Reference
11. AC power input terminals (L1, L2, L3, and PE)
12.Chassis ground terminal
1.6 VFD Indicator Lamps Description
The IT6000C series Bi-directional Programmable DC Power Supply VFD indica-
tor lamps description is as follows:
Table 1–1 VFD Indicator Lamps Description
Flag Function
Description
Flag Function Description
OFF The output of the
power supply is
turned off.
Sense Sense function of the power
supply is enabled.
CV The power supply is
in a state of con-
stant voltage
output.
Rear Analog function begin to
work.
CC The power supply is
in a state of con-
stant current output.
Addr When received command
successfully, the flag will dis-
play 3 seconds.
* The keyboard lock
is turned on.
Rmt Indicates that the instrument
is working in remote control
mode.
CR The power supply
(Sink) is in constant
resistance state.
Error Error occur
Shift Using composite
function key
Prot The instrument enters the
protection state.
SRQ Indicates that the
internal status re-
quest event occurs.
Trig The instrument is in a state
of waiting for a trigger.
CW The power supply is
in a state of con-
stant power output.
- -
Copyright © Itech Electronic Co., Ltd.
9
