Power Supply Function

The voltage difference between output terminal and remote sense terminal of

each model is not the same. When the remote sense terminal is connected re-

versely, the maximum voltage will not exceed the sum of output terminal voltage

and the difference voltage.

When Sense is reversed or short-circuited, the voltage meter value is dis-

played as a positive/negative value close to 0, and abnormal high voltage

output does not occur, which can avoid damage to the DUT.

4.6 Function Menu for Power Supply

The Function menu of the power supply includes the following:

Function Function Menu for Power Supply

LIST LIST program editing, file import/export, pro-

gram running (see 4.6.1 LIST Function).

BATTERY Battery charging and discharging testing

function (see 4.6.2 Battery Charging/Dis-

charging Test Function).

Road-Vehicles Built-in waveform function (see 4.6.3 Built-in

Waveform Function).

SAS PV simulation function (see 4.6.4 Solar Pho-

tovoltaic Curve Simulation Function (SAS)).

Battery Emulator Battery simulation test function (see 4.6.5

Battery Simulation Function).

4.6.1 LIST Function

The IT6000C series power supply supports a total of 10 List files (List01 to

List10), each of which can be set up to 200 steps. You need to edit the voltage/

current value, slope and time width of each step, or you can set repeat times (1

to 65535) for each List file. After the file is edited completely, you can trigger the

selected List file to run according to the selected trigger mode.

The descriptions of list function menu are listed in the table below.
