Power Supply Function
LIST List menu
Run Indicates to enter the List run mode, waiting for the trigger to
run the currently selected List file.
Open Select the List file to open.
USB Open the List file in the external USB flash disk.
Load Import the List file from the exter-
nal USB flash disk into the
instrument.
Not-Load Cancel the import operation.
Internal Open the List file stored inside the instrument.
Recall Inner
File
Set the name of the recalled List
file.
Export Export the internal List file of the instrument to an external
USB flash drive.
File
Name
The name of the exported list file. The default suf-
fix is .csv, and the file name can only be a string
of numbers.
Edit Edit list program.
CC / CV Set the operation mode for list program: CC prior-
ity or CV priority.
Step
Count
The total number of steps included in the List
program.
Step 1
Value
Current value or voltage value setting for Step1.
(The voltage appears when CV priority is se-
lected; the current appears when CC priority is
selected.)
Step 1
Slope
Slope value setting for Step1.
Step 1
Width
Dwell time setting for Step1. The range is from
0.001 to 864000 in seconds.
Repeat Set the number of list file repetitions.
End
State
Set the running state after the list program is run-
ning over.
Last After the List program finishes run-
ning, the output is kept as the
Copyright © Itech Electronic Co., Ltd.
71
