Power Supply Function

4.6.3.5 LV123

LV123 has been compiled for the electrical characteristics of new energy ve-

hicles for major European car manufacturers. For its high-voltage system parts,

the state standard within its operating voltage range is defined. The relevant pa-

rameters are introduced as follows:

Please pay attention to whether the voltage value defined in the LV123

standard matches the rated voltage of the instrument, otherwise some

waveforms cannot be recalled.

LV123 LV123 waveform protocol

Curv-

Choose to recall the standard LV123 waveform.

Run Run the presently recalled waveform.

Open Recall the waveform saved inside the

instrument.

Recall

File

The address of the waveform file,

ranging from 1 to 10.

Edit Edit the waveform curve.

unlimit-

Range of unlimited operating capabil-

ity, includes the following options:

• HV_1

• HV_2a

• HV_2b

• HV_3

upper-

limited

Range of upper limited operating ca-

pability, includes the following

options:

• HV_1

• HV_2a

• HV_2b

• HV_3

105
