Page #124 background image
Power Supply Function
Parameter HV_1 HV_2a HV_2b
r1 60S 60S 60S
t3 60S 60S 60S
f2 60S 60S 60S
t4 60S 60S 60S
r2 4mS 6mS 9mS
t5 60S 60S 60S
Actual number
of tests
Count*3 Count*3 Count*3
How to Use
The following is an example of how to use this function by recalling the LV123
standard regulation Unlimited and HV_1 waveform.
1. Press the composite keys [Shift]+[I-set] (Function) on the front panel to en-
ter the function menu.
2. Use the knob or press the Up/Down key to select 3.Road-Vehicles = Off
and press [Enter].
3. Press the Left/Right key to select LV123, and press [Enter] to confirm.
4. Press the Left/Right key to select Curve→Edit→unlimited→HV_1, and
press [Enter] to confirm.
5. Set start voltage = 50V, start time = 0.1S, end time = 0.1S and count = 1.
6. Set Save To File = 1, and press [Enter] to confirm.
7. Select Open→Recall File in the main interface of LV123. Set to 1, and press
[Enter] to confirm.
8. Select RUN in the main interface of LV123, and press [Enter] to confirm.
At this time, the information of the recalled waveform is displayed in the low-
er right corner of the VFD screen: R1/HV_1/00001, which is represented as
the interval type of the waveform, the type of the regulation, and how many
times the waveform has been executed cyclically.
9. Press [On/Off] on the front panel to turn on the output.
10.According to the selected trigger method (same as the trigger method of the
LIST function), for example, press [Shift]+[On/Off](Trigger) to trigger the
output of the waveform.
Copyright © Itech Electronic Co., Ltd.
112
