Power Supply Function
Step time Single-step pulse width. Single-step pulse width and
single-step repetition times can be set by selecting
one of them.
Step Repeat The number of repetitions of a single step. Single-
step pulse width and single-step repetition times can
be set by selecting one of them.
Step mode Operation mode, can be set to 0 or 1. When set to 0,
it means that the total running time Step DwelH and
the single-step pulse width Step time are used as the
running end condition; when set to 1, it means that
the single-step repetition times Step Repeat is used
as the running end condition.
End State Indicates the end state. Last (the voltage or current
maintained at the last step after the end) or Normal
(return to the normal mode before the Sweep is
executed).
The steps are as follows:
1. Edit the .csv file corresponding to the template on the PC and save it.
2. Save the edited file in the root directory of the U disk.
3. Insert the U disk into the front panel of the instrument.
4. Press the composite keys [Shift]+[I-set] (Function) on the front panel to
enter the function menu.
5. Select the 1. LIST: Off and press [Enter].
6. Press left/right key to select Open and press [Enter].
7. Select the USB and press [Enter].
At this point, the system will automatically read all the List files in the root
directory of the USB flash drive. The interface is displayed as follows:
XXX.csv
Not-Load Load YY/ZZ
XXX indicates the name of the List file; YY indicates the serial number of
the current List file; ZZ indicates the total number of the List file.
8. Press the Up/Down key to select the file.
9. Press the Left/Right key to select Load, press [Enter] to complete the
import, and wait for the trigger to run this file.
10.Turn on the [On/Off].
Copyright © Itech Electronic Co., Ltd.
80
