ITech IT6005C-80-150

Power Supply Function
a starting voltage of
24V.
User-defined
The user customizes
the starting voltage of
the automotive starting
waveform.
V=8.00V
User-de-
fined volt-
age value
DIN40839 for 12V System
Steps Voltage (V) Current(A) Width(mS) Slope(mS)
1 4.5 60 15 5
2 6 60 2000 5
3 12 60 T 10
DIN40839 for 24V System
Steps Voltage (V) Current(A) Width(mS) Slope(mS)
1 8V 60 50 10
2 12V 60 2000 5
3 24V 60 T 10
