Power Supply Function

Recall the Vehicle Waveform

Select any of the above five kinds of vehicle waveforms, after completing the

waveform parameter setting (see the subsequent introduction for each parame-

ter), the system will automatically enter the waveform recalling mode and wait

for the triggering operation. At this time, the VFD screen is displayed as the

main interface of the system, and the corresponding waveform name is dis-

played in the lower right corner.

Run the Vehicle Waveform

After turning on [On/Off], the output of the vehicle waveform is triggered accord-

ing to the selected trigger method.

The trigger method of the vehicle waveform is consistent with the trigger

method of the List function, that is, the List trigger source is also effective for

the vehicle waveform.

Stop the Vehicle Waveform Running

If you want to stop during the vehicle waveform output, you can do the following:

Press the composite keys [Shift]+[I-set] (Function) on the front panel to enter

the function menu.

At this point, the interface will prompt whether to stop the running of the Func-

tion, you can press the Left/Right key to select Stop, then the running will be

stopped, and the Function menu item will be displayed, you can re-enter the

Function menu for editing; if Reset is selected, it means to stop the present run-

ning and return to the main interface to wait for the next trigger operation; if

Pause is selected, it means that the present running is suspended, and you can

continue to run by selecting Resume.

4.6.3.1 Automotive Starting Waveform

The IT6000C series power supply has built-in 12V or 24V DIN40839 waveform.

This test verifies the behavior of a DUT during and after cranking. This wave-

form can reproduce the voltage curve for automotive power network confirms to

DIN40839 standard, thus facilitating quick call by customers.

For automotive startup voltage waveform, the startup voltage can also be set

based on customers’ requirements. In this way, the user can create waveform

between 8V to 32V.
