Power Supply Function
DIN40839 for 24V System
Steps Voltage (V) Current(A) Width(mS) Slope(mS)
1 8V 60 50 10
2 12V 60 2000 5
3 24V 60 T 10
User-defined Startup Voltage Waveform System
The user can define the startup voltage, ranging from 8V to 32V. When the
waveform program is divided into 8V-16V, the waveform is consistent with
standard 12V; when the waveform program is divided into 16V-32V, the wave-
form is consistent with the standard 24V waveform. The waveform diagram is
shown below.
Copyright © Itech Electronic Co., Ltd.
73
