Power Supply Function
LV123 LV123 waveform protocol
Curv-
e
Choose to recall the standard LV123 waveform.
Run Run the presently recalled waveform.
Open Recall the waveform saved inside the
instrument.
Recall
File
The address of the waveform file,
ranging from 1 to 10.
Edit Edit the waveform curve.
unlimit-
ed
Range of unlimited operating capabil-
ity, includes the following options:
• HV_1
• HV_2a
• HV_2b
• HV_3
upper-
limited
Range of upper limited operating ca-
pability, includes the following
options:
• HV_1
• HV_2a
• HV_2b
• HV_3
lower-
limited
Range of lower limited operating ca-
pability, includes the following
options:
• HV_1
• HV_2a
• HV_2b
• HV_3
highly-
limited
Range of highly limited operating ca-
pability, includes the following
options:
• HV_1
• HV_2a
• HV_2b
Copyright © Itech Electronic Co., Ltd.
91
