Quick Reference
Copyright © ITECH Electronics Co., Ltd. 9
6. up/down, left/right key
7. Rotary knob
8. output terminals
9. Ventle hole
2.3 Rear Panel Introduction
Rear panel of IT6121B/IT6122B/IT6123B/IT6132B/IT6133B.
1. Ventilation holes
2. RS232 interface
3. Qucik connect terminal for remote sensing and DVM terminal and external
control port
4. USB interface
5. GPIB interface
6. AC power inlet and fuse compartment
Rear panel of IT6162B.
OFF
1.000V 1.0000A
0.0001V
The actual output voltage
value and current.
