ITech IT6302 - Current Operation; Save and Recall Operation

IT6302 user manual
USER MANUAL
19
Solution 3: Press
V-setV-set
,then press to move the cursor position and adjust the
voltage value using . Press
Esc
or
Enter
to exit.
Note: When output in OFF mode and button is dark, rotary knob and up/down
keys cannot be used to adjust voltage and current.
If rotary knobs are enabled, then adjusting it will real-time to change the current
output setup without press
Enter
to confirm.
3.5.4 Current Operation
Solution 1: press (Local) to select channel, press
I-setI-set
then enter a numerical value
followed by
Enter
.
Solution 2: Press
I-setI-set
, then press to move the cursor position and adjust the
current value using the knob.Press
Esc
or
Enter
to exit.
Solution 3: Press
I-setI-set
, then press to move the cursor position and adjust the
current value using . Press
Esc
or
Enter
to exit.
3.5.5 Save and Recall Operation
You can store up to 27 different operating states in memory locations 1 through 27.They are
divided to three groups, each group includes nine different setups. Each operating state
includes a constant voltage value, constant current value, maximum output voltage.
Press (Shift) +
Recall
(Save) followed by a number key to save the current operating
state to non volatile memory.
Press
Recall
+number 1 to 9 to recall operating state assigned to this location.
You can also use the SCPI command (*SAV, *RCL) to save and recall.
When Save operation is done,there will be a corresponding information to indicate the
successful or failed operation.While for Recall operation,only information to indicate failed
recall.
Note: The power supply doesn’t support Save/Recall operation when in serial/parallel
or tracking mode.
If in serial/parallel mode and do Save/Recall operation, the VFD will display INV OPER
(invalid Operation) to remind the user of a wrong operation.
If parameters want to be recalled do not exist, the current value position on VFD will
display -----, and then resume after 2S.
