(8) VFD display NEXT >YES，press
Enter
to confirm.
(9) Repeat the steps from 5) to 8) and set the four steps’ voltage/current and delay time
separately. When screen display NEXT>YES in the fourth step edit process,please press
to select NEXT >NO,press
Enter
to confirm.
(10) VFD display REPET 1，press number key
0
to
9
or rotary knob to set the repeat
times，press
Enter
to confirm.
(11) VFD display SAVE >NO，press
Enter
to confirm，in this circumstance,the list file is
not saved but can run for one time,or you can press
button to select >SAVE
FILE0,saving the list test file in FILE0~FILE9，press
Enter
to confirm.You can recall the
file in the following utilization.
(12) If you do not save the list test file,VFD will display LIST EDIT;if you select to save the
test file,VFD will display SAVE DONE for three seconds,and then display LIST EDITL.
Set List State
(13) Press
to select >LIST STATE item，press
Enter
to confirm.
(14) VFD display LIST >OFF, press
to select >LIST >ON, press
Enter
to
confirm.Now
Enter
button will be lit.This indicates that list operation function has been
opened.
(15) VFD display >LIST STATE，pressing
Esc
button can quit the operation.
Run list file
(16) Press
On/Off
button to open the output，press (Shift)+
Enter
（Trigger）to give
a trigger signal.
Recall list file
(17) If you have edited several list files,you can select LIST LOAD item to recall the file
you need.And then press
Esc
to quit this operation.Press
On/Off
button to open the
output.Now you only need to press
(Shift)+
Enter
(Trigger) to give a trigger signal,the list
file can be ran.
Quit list file
(18) In LIST mode,voltage set and current set button can’t be used,In LIST STATE
item,choose LIST>OFF will enable you to quit list mode.
