SCPI Status Register
Copyright ©ITECH Electronic Co., Ltd. 13
change of the constant current and voltage status via the register, for
example, data bit 0 is the constant voltage mode of the power supply,
data bit 1 is constant current mode of the power supply, and so on.
Bit
Decimal
Value
Definition
0
CV
1
The power supply is/was in the constant
voltage mode.
1 CC 2
The power supply is/was in the constant
current mode.
2-3
Not used
0
Always set to 0.
4
Over
temperature
16
The fan has a fault condition.
5-8
Not used
0
Always set to 0.
9
Over
voltage
512
The overvoltage protection circuit has tripped.
10
Over
Current
1024
The over current protection circuit has tripped.
11-
15
Not used 0 Always set to 0.
Status byte register records the information of other registers. The query data is
temporally stored in the output buffer of the power supply, and feedback to
customer through BIT4 bit. The data bits in Status byte group will not be latched,
when the information in event register is changed, the correspo0nding bit in
status byte register will subsequently be changed.
Bit
Decimal
Value
Definition
0-1
Not used
0
Always set to 0.
2
EAV
4
Error buffer available
3
QUES
8
One or more bits are set in the questionable
status register (bits must be “enabled” in the
enable register).
4 MAV 16
Data is available in the power supply output
buffer.
5
ESB
32
One or more bits are set in the standard event
register (bits must be “enabled” in the enable
register).
6 RQS 64 The power supply is requesting service (serial
poll).
7
Not used
0
Always set to 0.
The below picture will give you more detailed information:
