Operation and Application
Copyright ©ITECH Electronic Co., Ltd. 51
⚫ Standards Selection Area
In the Standards selection area, users can select the regulation to be tested.
Each option is described as follows:
Select the regulations to be tested.
the following regulations are supported:
⚫ IEC 61000-4-11
⚫ IEC 61000-4-13
⚫ IEC 61000-4-14
⚫ IEC 61000-4-28
Test items defined by standard regulations.The three
projects are divided into several sub-projects according to
the requirements defined by regulations, and customers
select them according to the level of needs.
Voltage dips
short interruptions
Voltage variations
Voltage value of AC output. User can setting the voltage
level according to the DUT requirements.
Frequency value of AC output. Different regulations have
different definitions. This parameter can be set only for
User defined categories.
Select the phase to execute the test. If not selected, the
test as defined by the regulation will not occur.
⚫ Standards Edit Area
The execution items and parameters in the regulation editing area are
different for different regulation items.
You can edit parameters such as the start Angle of test execution. The
parameters displayed in green on the page can be modified.
This section uses IEC 61000-4-11 as an example to describe the regulatory
parameters. For other regulation parameters, see the regulation standard.
Level of test items defined by the regulation.
The starting phase Angle position of the A-phase waveform
output.
For three-phase mode, the Angle difference between PHASE
B and A is 120°, PHASE C and A is 240°
The number of continuous periods for maintaining the drop
voltage, According to regulations, different test items have
different cycles.
The interval time of test, from the beginning of the drop to the
recovery of normal operation. Unit: second (s)
Time delay, the time interval between test items. Unit: second
