ITech IT7800 Series User Manual

System-Related Functions
Copyright ©ITECH Electronic Co., Ltd. 55
on, the instrument will remain
the same settings as last time you
turned off the instrument,
but the [On/Off] is OFF state.
Parallel mode
Set the instruments to parallel operation mode.
Parallel
⚫ Master: Set the instrument to
master mode.
Single: Set the instrument to single
mode, i.e., disable the parallel
⚫ operation mode.
⚫ Slave: Set the instrument to
slave mode.
Numbers
Number of parallel instruments.
Touch function
Lock the touch screen function
Status
Set the ON/OFF state
Knob immediately
effective
Knob setting will take effect immediately. If set to ON,
the Knob setting will take effect immediately. If set to
OFF, press ENTER to confirm the effect after the Knob
setting is completed.
Language
Set the language of display
English
English
Chinese
Chinese
Soft keyboard
Set the soft keyboard
On
Turn on the soft keyboard.
Off
Turn off the soft keyboard.
Communication
USB type
Set the USB type.
DEVICE: the USB device is used to communication
with PC.
HOST: the USB device is used to storage disk.
USB device class
USB communication interface
VCP
Virtual serial port
TMC usbtmc
USB-TMC protocol
LAN config
LAN communication interface
Mode
⚫ DHCP: automatically configure
the address of the instrument.
⚫ Manual: manually configure
the address of the instrument
by entering values in the
following five fields.
IP
Set the IP address.
Mask
Set the subnet mask.
Gateway
Set the gateway address.
Port
Set the port number.
CAN config
CAN communication interface.
Baud rate
Select the baud rate
Addr
Set the instrument address to a
number
RS232 config
Select RS-232 communication interface. When insert
IT-E177 communication board into expansion slot,
the menu displays this information.
Baud rate
Baud rate
Databits
Data bit: 5/6/7/8
Stopbits
Stop bit: 1/2
