System-Related Functions
Copyright ©ITECH Electronic Co., Ltd. 56
Parity bit: N (No parity) / E (Even
parity) / O
(Odd parity)
Select GPIB communication interface. When insert IT-
E176 communication board into expansion slot, the
menu displays this information.
Set the communication address
Digital IO-1:Remote
Inhibit Input
Function setting of pin 1
On/Off, Select Invert or not under
the IO Settings. If setting to ON, it
means the valid signal is reversed.
⚫ Inhibit-living
⚫ Inhibit-latch
⚫ Input
⚫ Output
Function setting of pin 2
On/Off, Select Invert or not under
the IO Settings. If setting to ON, it
means the valid signal is reversed.
⚫ PS Clear
⚫ Input
⚫ Output
Function setting of pin 3
On/Off, Select Invert or not under
the IO Settings. If setting to ON, it
means the valid signal is reversed.
Function setting of pin 4
On/Off, Select Invert or not under
the IO Settings. If setting to ON, it
means the valid signal is reversed.
⚫ Sync-in
⚫ Sync-out
⚫ Input
⚫ Output
Digital IO-5:
ON/OFF Status
Function setting of pin 5
On/Off, Select Invert or not under
the IO Settings. If setting to ON, it
means the valid signal is reversed.
ON/OFF Status
Input
Output
Function setting of pin 6
On/Off, Select Invert or not under
the IO Settings. If setting to ON, it
means the valid signal is reversed.
⚫ Trigger1-out
⚫ Trigger1-in
