ITech IT7800 Series User Manual

System-Related Functions
Copyright ©ITECH Electronic Co., Ltd. 57
⚫ Input
⚫ Output
AC
On/Off: When On is selected, a
trigger signal is output when AC
amplitude changes. The accuracy
of voltage change is 100mV and is
not restricted by phase.
(This configuration is displayed
only when the IO function is set to
Trigger1-out)
DC
On/Off: When On is selected, a
trigger signal is output when the
DC amplitude changes, and the
voltage change precision is
100mV.
(This configuration is displayed
only when the IO function is set to
Trigger1-out)
Freq
On/Off: When On is selected, a
trigger signal is output when the
frequency changes.The accuracy
of frequency change is 0.1Hz
(This configuration is displayed
only when the IO function is set to
Trigger1-out)
List
On/Off: When On is selected, a
trigger signal is output when the
List generates a trigger signal.
(This configuration is displayed
only when the IO function is set to
Trigger1-out)
Digital IO-7: TRIG2
Function setting of pin 7
Reverse
On/Off
Fun
Trigger1-out
Trigger1-in
Input
Output
AC
On/Off: When On is selected, a
trigger signal is output when AC
amplitude changes. The accuracy
of voltage change is 100mV and is
not restricted by phase.
(This configuration is displayed
only when the IO function is set to
Trigger2-out)
DC
On/Off: When On is selected, a
trigger signal is output when the
DC amplitude changes, and the
voltage change precision is
100mV.
(This configuration is displayed
only when the IO function is set to
Trigger2-out)
Freq
On/Off: When On is selected, a
trigger signal is output when the
frequency changes.The accuracy
