ITech IT7930-350-180 - Current RMS Protection

System-Related Functions
Copyright ©ITECH Electronic Co., Ltd. 47
Time
delay time of protection
Voltage peak range
Voltage peak range setting
V limit
Maximum voltage setting
Power limit range
Power limit setting
P limit
Power limit point
Time
delay time of protection
Type
Protection type.
Limit
Shutup
DC/DCAC Mode
Press [Shift]+[Config] (Protect) and enter to Protect configure menu, where
you can set the following protection.
Current limit range
Current limit setting
I+ limit
Maximum current setting, the
current setting will be limited to
this range.
I- limit
Minimum current setting, the
curren
t setting will be
limited to
this range.
Voltage limit range
Voltage limit setting
V+ limit
Maximum voltage setting, the
voltage setting will be limited to
this range.
V- limit
Minimum voltage setting, the
voltage setting will be limited to
this range.
Power limit range
Power limit setting
P+ limit
Maximum power setting, the
power setting will be limited to this
range.
P- limit
Minimum power setting, the power
setting will be limited to this range.
5.5.1 Current RMS Protection
The user can set the over-current protection point, delay time and protection
type for the Current RMS protection function. The function is mainly used to
protect the DUT connected during test to prevent it from damage due to over-
current. The OCP (rms) function is always enabled.
RMS OCP Type:
z Limit: If the output current reaches the RMS current protection point, the
protection will be activated. The power supply output current is controlled
within the current limiting value. The power supply will output in CC mode.
z Shutup: When the output current reaches the over-current protection point
and the period is greater than the set protection delay time, the over-current
protection (rms) will turn off the output.
How to Set
1. Press [Shift]+[Config] (Protect) keys and enter to Protection menu.
2. Press the up/down key or rotate the knob to select Current RMS protection
and press [Enter].
