Inspection and Installation
Copyright ©ITECH Electronic Co., Ltd. 73
as determined by the subnet mask setting. The same numbering notation
ap- plies as for the IP Address. A value of 0.0.0.0 indicates that no default
gate- way is defined.
•
DNS: This field enters the primary address of the server. Contact your LAN
administrator for server details. The same numbering notation applies as for
the IP Address. A value of 0.0.0.0 indicates that no default server is defined.
DNS is an internet service that translates domain names into IP addresses. It is
also needed for the instrument to find and display its hostname assigned by the
network. Normally, DHCP discovers the DNS address information; you only need
to change this if DHCP is unused or not functional.
•
Socket Port: This value indicates the port number corresponding to
the service.
Server Config
Configurable services include: MDNS, PING, Telnet-scpi, Web, VXI-11, and Raw
Socket.
How to Configure
Take manual configuration as an example. The steps are as follows:
1.
Press the composite keys [Shift]+ (System) on the front panel
to enter the system menu.
2.
Select Communication and press [Enter].
3.
Press the Left/Right key to select LAN and set the mode to Manual.
4.
Set the IP, Mask and the other parameters in turns, and press [Enter].
Using Web Server
The instrument has a built-in Web server for monitoring and controlling the in-
strument via a Web browser in PC. To use the Web server, connect the instru- ment
and PC over LAN interface and enter the instrument's IP address into the address bar
at the top of your PC's Web browser, you can access the front pan- el control
functions including the LAN configuration parameters.
•
If you want to remotely control the instrument using the built-in web server,
you must enable the web service.
•
The format of the address entered in the address bar of the browser is
http:// 192.168.0.100. The specific IP address is subject to the actual
instrument settings.
