Specifications
Copyright © Itech Electronic Co., Ltd. 54
Protection range
OPP
Protection
≒160W
≒320W
OCP
Protection
≒3.3A
≒33A
≒3.3A
≒33A
OVP
Protection
≒160V
≒160V
OTP
Protection
≒85℃
≒85℃
Specification
Short
Current( CC )
≒3.3/3A
≒33/30A
≒3.3/3A
≒33/30A
Voltage( CV )
0V
0V
0V
0V
Resistance( CR
)
≒80mΩ
≒80mΩ
≒40mΩ
≒40mΩ
Input
Impendance
150KΩ
150KΩ
Dimension
214.5mm*88.2mm*354.6mm
214.5mm*88.2mm*354.6mm
*1 The voltage/current input is no less than 10% FS
*2 The scope of read-back resistance is: (1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08))
*3 The voltage/current input is no less than 10% FS
*4 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current.
*5 Minimum rise time: 10%-90% current rise time
Model
IT8511B+
Rated value
( 0~40 ℃)
Input voltage
0~500V
Input current
0~3A
0~10A
Input power
150W
Minimum
operation
value
1.2V at 3A
4V at 10A
CV mode
Range
0.1~50V
0.1~500V
Resolution
1mV
10mV
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.05%FS)
CC mode
Range
0~3A
0~10A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.05%FS)
CR mode
*1
Range
0.5Ω~10Ω
10Ω~7.5KΩ
Resolution
16bit
Accuracy
0.01%+0.08S *2
0.01%+0.0008S
CP mode
*3
Range
150W
Resolution
10mW
Accuracy
0.1%+0.2%FS
Dynamic mode
Dynamic
mode
CC mode
T1&T2
20uS~3600S /Res:1 uS
Accuracy
2uS±100ppm
Rising/Falling
slope *4
0.0001~0.2A/uS
0.001~0.8A/uS
Minimum rise
time *5
≒10uS
≒10uS
Measuring range
Readback
voltage
Range
0~50V
0~500V
Resolution
1 mV
10 mV
Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback
current
Range
0~3A
0~10A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
