Specifications
Copyright © Itech Electronic Co., Ltd. 55
Readback
power
Range
150W
Resolution
10mW
Accuracy
±(0.1%+0.2%FS)
Protection range
OPP
Protection
≒160W
OCP
Protection
≒3.3A
≒11A
OVP
Protection
≒530V
OTP
Protection
≒85℃
Specification
Short
Current( CC )
≒3.3/3A
≒11/10A
Voltage( CV )
0V
0V
Resistance( C
R )
≒400mΩ
≒400mΩ
Input
Impendance
1MΩ
Dimension
214.5mm*88.2mm*354.6mm
*1 The voltage/current input is no less than 10% FS
*2 The scope of read-back resistance is: (1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08))
*3 The voltage/current input is no less than 10% FS
*4 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current.
*5 Minimum rise time: 10%-90% current rise time
Model
IT8512B+
Rated value
( 0~40 ℃)
Input voltage
0~500V
Input current
0~3A
0~15A
Input power
300W
Minimum
operation
value
0.6V at 3A
3V at 15A
CV mode
Range
0.1~50V
0.1~500V
Resolution
1mV
10mV
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.05%FS)
CC mode
Range
0~3A
0~15A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.05%FS)
CR mode
*1
Range
0.3Ω~10Ω
10Ω~7.5KΩ
Resolution
16bit
Accuracy
0.01%+0.08S *2
0.01%+0.0008S
CP mode
*3
Range
300W
Resolution
10mW
Accuracy
0.1%+0.2%FS
Dynamic mode
Dynamic
mode
CC mode
T1&T2
20uS~3600S /Res:1 uS
Accuracy
2uS±100ppm
Rising/Falling
slope *4
0.0001~0.2A/uS
0.001~0.8A/uS
Minimum rise
time *5
≒10uS
≒10uS
Measuring range
Readback
voltage
Range
0~50V
0~500V
Resolution
1 mV
10 mV
