Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback
current
Range
0~3A
0~15A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
Readback
power
Range
300W
Resolution
10mW
Accuracy
±(0.1%+0.2%FS)
Protection range
OPP
Protection
≒320W
OCP
Protection
≒3.3A
≒16A
OVP
Protection
≒530V
OTP
Protection
≒85℃
Specification
Short
Current( CC )
≒3.3/3A
≒16/15A
Voltage( CV )
0V
0V
Resistance(
CR )
≒180mΩ
≒180mΩ
Input
Impendance
1MΩ
Dimension
214.5mm*88.2mm*354.6mm
*1 The voltage/current input is no less than 10% FS
*2 The scope of read-back resistance is: (1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08))
*3 The voltage/current input is no less than 10% FS
*4 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current.
*5 Minimum rise time: 10%-90% current rise time
Model
IT8512C+
Rated value
( 0~40 ℃)
Input voltage
0~120V
Input current
0~6A
0~60A
Input power
300W
Minimum
operation
value
0.25V at 6A
2.5V at 60A
CV mode
Range
0.1~18V
0.1~120V
Resolution
1mV
10mV
Accuracy
±(0.05%+0.02%FS)
±(0.05%+0.025%FS)
CC mode
Range
0~6A
0~60A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.1%FS)
CR mode
*1
Range
0.05Ω~10Ω
10Ω~7.5KΩ
Resolution
16bit
Accuracy
0.01%+0.08S *2
0.01%+0.0008S
CP mode
*3
Range
300W
Resolution
10mW
Accuracy
±(0.1%+0.3%FS)
Dynamic mode
Dynamic
mode
CC mode
T1&T2
20uS~3600S /Res:1 uS
Accuracy
2uS±100ppm
Rising/Falling
slope *4
0.0001~0.3A/uS
0.001~3A/uS
