ITech IT8500plus Series User Manual

Specifications
Copyright © Itech Electronic Co., Ltd. 57
Minimum rise
time *5
≒10uS
≒10uS
Measuring range
Readback
voltage
Range
0~18V
0~120V
Resolution
0.1 mV
1 mV
Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback
current
Range
0~6A
0~60A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.1%FS)
Readback
power
Range
300W
Resolution
10mW
Accuracy
±(0.1%+0.3%FS)
Protection range
OPP
Protection
≒320W
OCP
Protection
≒6.5A
≒65A
OVP
Protection
≒125V
OTP
Protection
≒85℃
Specification
Short
Current( CC )
≒6.5/6A
≒65/60A
Voltage( CV )
0V
0V
Resistance( C
R )
≒40mΩ
≒40mΩ
Input
Impendance
150KΩ
Dimension
214.5mm*88.2mm*354.6mm
*1 The voltage/current input is no less than 10% FS
*2 The scope of read-back resistance is: (1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08))
*3 The voltage/current input is no less than 10% FS
*4 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current.
*5 Minimum rise time: 10%-90% current rise time
Model
IT8512H+
Rated value
( 0~40 ℃)
Input voltage
0~800V
Input current
0~1A
0~5A
Input power
300W
Minimum
operation
value
1.4V at 1A
7V at 5A
CV mode
Range
0.1~80V
0.1~800V
Resolution
1mV
10mV
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.05%FS)
CC mode
Range
0~1A
0~5A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.1%FS)
±(0.05%+0.05%FS)
CR mode
*1
Range
2Ω~10Ω
10Ω~7.5KΩ
Resolution
16bit
Accuracy
0.01%+0.08S *2
0.01%+0.0008S
CP mode
*3
Range
300W
Resolution
10mW
Accuracy
0.2%+0.2%FS
Dynamic mode
