Quick Start
Copyright © ITECH Electronic Co., Ltd. 19
⚫ The rear panel of IT8617 15U cabinet (three masters) is shown in the next
figure.
Before connecting the communication terminals, load input terminals and
remote measurement terminals, you need to take apart the rear panel
which covers the communication terminals by using a screwdriver. These
terminals are the same as those of IT8615.
1. Communication interface and test line threading hole
2. Power master switch
3. AC power cord threading hole
