3.18 Three-phase Function
IT8600 can be used to test three-phase AC power supplies. The AC load can be
operated in the CC/CR/CP mode. In three-phase applications, the user can
select Y-type and Δ-type connection according to actual requirements. The
flexible connection meets various test requirements.
NOTE
Only IT8615, IT8615L and IT8620 series are with the function.
Take the example of IT8615 electronic load, the schematic diagram of
three-phase connection is as follows. When you connect system bus, the
Terminating Resistor is a must for the first load unit and the last load unit.
