ITL HD 7515 - Page 7

1
2
3
4
10
5
6
7
main
unit
8
9
motor
head
7
Schematic
INSTALLATION IN PARALLEL
1. Circuit breaker
2. Low voltage connector
3. Serial number
4. Air intakes (seal the unused air
intake with the provided cap)
5. Intake for installation in parallel
6. Intake for installation in series
7. Mufer (optional)
8. Air exhaust
9. Carbon dust lters
10. LCD monitor
