1
2
3
4
5
10
6
7
main
unit
8
9
motor
head
6
INSTALLATION IN SERIES
1. Circuit breaker
2. Low voltage connector
3. Serial number
4. Air intakes (seal the unused
air intake with the provided cap)
5. Intake for installation in parallel*
6. Intake for installation in series
7. Mufer (optional)
8. Air exhaust
9. Carbon dust lters
10. LCD monitor
*In this case, this intake should be sealed with a cap.
Preface
Your new central vacuum system was designed and manufactured in Blainville,
Quebec, by the largest central vacuum cleaner manufacturer in Canada. With
over fty years of experience in the eld, we provide a high-quality, state-of-the-
art product, and guarantee your complete satisfaction. Our extensive network of
qualied professionals ensures rst quality service near you. Contact us for the
location of the authorized dealer in your area.
