General Information
1-6 CENTRON Meter Technical Reference Guide
Characteristic Data
Burden Data
To get the watt loss or VA of the overall product, add the metrology watt loss to the
register watt loss and option board watt loss.
Starting Watts
2S CL200 5W
1S, 2S CL320, 12S, 25S 10W
3S CL20 1.2W
4S CL20 2.4W
Temperature Rise Meets ANSI C12.1 Section 4.7.2.9
Metrology Voltage Watt Loss VA
1S 120 0.45 3.7
2S Class 200 240 0.45 7.2
2S Class 320 240 0.65 10.2
3S 240 0.65 10.2
4S 240 0.65 10.2
12S/25S 120 0.65 5.4
240V
Register
LCD R300 CellNet D/T/L
Watt Loss 0.01 1.34 1.34 0.90
VA — 0.25 0.25 14.76
120V
Register
LCD R300 CellNet D/T/L
Watt Loss 0.01 0.62 0.62 0.90
VA — 0.14 0.14 11.1
120V Option Board R300CD
Watt Loss 2.2
VA 23
240V Option Board
Watt Loss 2.2
VA 42
VA (Meter) VA (Metrology) VA (Register) + VA (Option Board)+=
Watt Loss (Meter) Watt Loss (Metrology) Watt Loss (Register) + Watt Loss (Option Board)+=
